☆型号:IC693MDL740H 正逻辑直流输出模块 LED 指示灯传达电路的状态
【产品详情】
GE Fanuc 90-30 系列 IC693MDL740 是一款 12/24 正逻辑直流输出模块。该模型具有正逻辑,因此模块将电流从正电源总线端子或普通用户源到所需负载。输出电子设备放置在输出模块和电源总线之间。 IC693MDL750模块所需的额定电压为 12/24 伏直流电,输出电流最大为 0.5 安培/点,最大 2 安培/共端。
IC693MDL740设计有 16 个公共点,分为两个相等的组。每组有 8 个输出点和一个公共输出引脚。该模块的架构有一个铰链门,可以在外表面和内表面之间放置一个插件。当该门关闭时,铰链门的内表面包含电路的接线信息,而外表面包含有关电路的识别信息。插件左侧的蓝色表示IC63MDL740模块是低音量tage 模块。
IC693MDL740有一个 LED 指示灯,用于传达电路的状态。LED 指示灯包含两排带有绿色 LED 灯的水平行,其中顶行标记为 A1,底行标记为 B1。
与该模块一起使用的现场设备由外部电源操作。它可以安装在 90-30 可编程逻辑控制系统的任何输入或输出插槽中。
☆型号:IC693MDL740H 正逻辑直流输出模块 LED 指示灯传达电路的状态
【英文介绍】
The GE Fanuc 90-30 Series IC693MDL740 is a 12/24 positive logic DC output module. The model has positive logic, so the module passes the current from the positive power bus terminal or a normal user source to the desired load. The output electronics are placed between the output module and the power bus. The IC693MDL750 module requires a rated voltage of 12/24 volts DC with an output current of up to 0.5 amps/point and up to 2 amps/common terminal.
The IC693MDL740 design has 16 common points divided into two equal groups. Each group has 8 output points and a common output pin. The architecture of the module has a hinged door that allows a plug-in to be placed between the outer and inner surfaces. When the door is closed, the inner surface of the hinged door contains wiring information of the circuit, while the outer surface contains identifying information about the circuit. The blue color on the left side of the plug-in indicates that the IC63MDL740 module is a low volume tage module.
The IC693MDL740 has an LED indicator that communicates the status of the circuit. The LED indicator consists of two horizontal rows with green LED lights, where the top row is labeled A1 and the bottom row is labeled B1.
The field equipment used with this module is operated by an external power supply. It can be installed in any input or output slot of a 90-30 programmable logic control system.
