IC200MDL730E Max系列离散输出模块 分立式输出模块

☆型号：IC200MDL730E Max系列离散输出模块 分立式输出模块

【产品详情】

该IC200MDL730由GE自动化控制公司制造，是一款VersaMax系列分立式输出模块。 该器件提供一组 8 个输出点，可以是正逻辑或源极类型。该模块上的输出点负责将负载切换到电源的正极，从而为所有负载提供电流。

除了标准背板电源外，该模块还需要外部直流电源来实现输出负载切换。背板电源必须稳定至少一秒钟，然后此设备才能接受现场电源。如果在背板稳定之前施加现场电源，则可能会发生错误的输出点故障。如果检测到短路，需要外部电源为本产品提供足够的现场电源。有关进一步的外部电源要求，请参阅产品文档。

该IC200MDL730提供故障检测诊断，并可确定是否发生了过载或短路。该模块上的每个输出点都具有以下保护机制：电子短路保护 （ESCP） 和过流保护;但是，不支持通道间隔离。

在 30 伏直流电下工作时，每个输出点能够处理高达 2 安培的电流，整个模块能够驱动最大 8 安培的电流。5 伏背板消耗的电流量为 50 毫安。该模块的输出电压为 17.5 至 30 伏直流电。标称输出电压为 24 伏直流电，可接受 0.5 伏的最大输出电压降。

☆型号：IC200MDL730E Max系列离散输出模块 分立式输出模块

【英文介绍】

The IC200MDL730, manufactured by GE Automation and Control, is a VersaMax series discrete output module. The device provides a set of 8 output points, which can be of either positive logic or source type. The output point on this module is responsible for switching the load to the positive terminal of the power supply, thus providing current to all the loads.

In addition to the standard backplane power supply, the module also requires an external DC power supply for output load switching. The backplane power supply must be stable for at least one second before this device can accept field power. If field power is applied before the backplane is stabilized, a false output point failure may occur. If a short circuit is detected, an external power supply is required to provide sufficient on-site power for this product. Refer to the product documentation for further external power requirements.

The IC200MDL730 provides fault detection diagnosis and can determine if an overload or short circuit has occurred. Each output point on the module has the following protection mechanisms: Electronic short circuit protection (ESCP) and overcurrent protection; However, inter-channel isolation is not supported.

Operating at 30 volts DC, each output point is capable of handling up to 2 amps, and the entire module is capable of driving up to 8 amps of current. The 5-volt backplane consumes 50 mah of current. The module has an output voltage of 17.5 to 30 volts DC. The nominal output voltage is 24 volts DC and can accept a maximum output voltage drop of 0.5 volts.
