IS220YAICS1A 模拟I/O组端子板之一 小型银色端子

☆型号：IS220YAICS1A 模拟I/O组端子板之一 小型银色端子

【产品详情】

IS200STAIS2A机组是什么类型的型号？

IS200STAIS2A型号是Mark VI模拟I/O组端子板之一。通常，在操作时，IS200STAIS2A型号可与Mark VIeS安全模拟I/O包配合使用。I/O 包标记为 IS220YAICS1A I/O 包。除了IS220YAIC型号外，IS200STAIS2A单元还可以与IS2000STAIS1A、IS400STAIS1A、IS400STAIS2A、IS200TBAIS1C和IS400TBAIS1C一起使用。有关这些型号如何协同工作的信息，请参阅 GEH-6725 使用手册。

美国和加拿大 I 类 2 区 STAIS 型号的设备标记是什么？

美国和加拿大 I 类 2 区 IS200STAIS2A 型号的标记是 I 类、2 区、AEx nA nC [nC] IIC T4、Ex nA nL [nL] IIC T4 Gc X。IS200STAIS2A型号上还可以使用其他设备标记，有关这些标记，请参阅 GEH-137 使用说明书第 6725 页。

产品描述

IS200STAIS2A是通用电气或通用电气的Mark VI（MKVI）系列中的印刷电路板或PCB组件。该型号被通用电气标识为 Mark VI 模拟 I/O 组端子板。该型号将与 IS220YAICS1A Mark VI 安全模拟 I/O 包结合使用。该型号通常称为欧式盒式接线端子。

IS200STAIS2A接线端子包含多达四十八 （48） 个由金属制成的小型银色端子。每个终端都用白色字体写的编号进行标识。长连接器端口放置在IS200STAIS2A的另一端。端口是黑色的，许多小的母连接器安装在银色金属上。各种不同的电子元件在IS200STAIS2A的中心垂直排列。在这些元件中，有十个黑色电位器或可变电阻器。每个电位器旁边都有一个半圆形的黑色小晶体管。四 （4） 个附加电位计分组在IS200STAIS2A的右下角。其中有二十 （20） 个同样是黑色的跳线。每个跳线连接一对由银色金属制成的跳线引脚，从而改变了电路板的功能。在IS200STAIS2A的右半部分放置了几个黄色小电容器。这些黄色电容器的形状像非常小的矩形。在IS200STAIS2A的各个地方也可以看到一些集成电路。这些集成电路很小，并且包含微小的组件网络。

IS200STAIS2A模型可用于危险和非危险场所之间的多种分类位置认证。该型号的非危险位置标记为 UL E207685;I 类 2 区 A、B、C、D 组和 I 类 2 区 IIC 组具有相同的认证。

☆型号：IS220YAICS1A 模拟I/O组端子板之一 小型银色端子

【英文介绍】

What type of IS200STAIS2A unit is?

The IS200STAIS2A model is one of the Mark VI analog I/O group terminal boards. In general, when operating, the IS200STAIS2A model can be used with the Mark VIeS secure analog I/O package. The I/O package is marked as IS220YAICS1A I/O package. In addition to the IS220YAIC model, the IS200STAIS2A unit can also be used with the IS2000STAIS1A, IS400STAIS1A, IS400STAIS2A, IS200TBAIS1C, and IS400TBAIS1C. For information on how these models work together, see the GEH-6725 operator's manual.

What is the equipment marking for STAIS Type I Region 2 in the United States and Canada?

U.S. and Canadian Class I Zone 2 IS200STAIS2A models are labeled Class I, Zone 2, AEx nA nC [nC] IIC T4, Ex nA nL [nL] IIC T4 Gc X. Additional equipment markings may be used on the IS200STAIS2A model, for which please refer to page 6725 of the GEH-137 operating instructions.

Product description

The IS200STAIS2A is a printed circuit board or PCB assembly from General Electric or GE's Mark VI (MKVI) series. This model is identified by General Electric as the Mark VI Analog I/O group terminal board. This model will be used in conjunction with the IS220YAICS1A Mark VI Secure analog I/O package. This model is commonly referred to as the European box terminal.

IS200STAIS2A terminals contain up to forty-eight (48) small silver terminals made of metal. Each terminal is identified by a number written in white font. The long connector port is placed on the other end of the IS200STAIS2A. The ports are black, and many small female connectors are mounted on silver metal. Various electronic components are arranged vertically in the center of the IS200STAIS2A. Among these elements are ten black potentiometers or variable resistors. Next to each potentiometer is a small, semi-circular black transistor. Four (4) additional potentiometers are grouped in the lower right corner of IS200STAIS2A. Twenty (20) of them are also black jumpers. Each jumper is connected to a pair of jumper pins made of silver metal, thus changing the function of the board. Several small yellow capacitors are placed in the right half of IS200STAIS2A. These yellow capacitors are shaped like very small rectangles. Some integrated circuits can also be seen in various parts of the IS200STAIS2A. These integrated circuits are small and contain tiny networks of components.

The IS200STAIS2A model can be used for multiple classification location certification between hazardous and non-hazardous sites. The non-hazardous position for this model is labeled UL E207685; Class I Area 2 Groups A, B, C, D and Class I Area 2 IIC Group have the same certification.
