Bently 3500/33   16 通道继电器模块

【产品详情】

3500/33 是由 Bently Nevada 开发的 16 通道继电器模块。具有 16 个继电器输出的全高模块，即 16 通道继电器模块。瞬态数据接口 (TDI) 模块右侧的任何插槽均可容纳任意数量的 16 通道继电器模块。投票逻辑可以单独编程到 16 通道继电器模块的每个输出中。报警驱动逻辑是模块中每个继电器的一个组件。以下是使用 AND 和 OR 逻辑对报警驱动逻辑进行可能编程的

警报源（警报和危险状态）

不好

从机架中的任何监视器通道或一组监视器通道单独测量的变量

3500 机架配置软件可用于对报警驱动器进行编程。

输入规格

5.8 瓦是平均输入功耗。

输出规格

前面板 LED：16 通道继电器模块的 OK LED 在正常工作时会亮起。

当 16 通道中继模块与 3500 机架中的其他模块通信时，代表发送和接收的 TX/RX LED 会闪烁。

当中继通道处于报警状态时，通道报警 LED 会亮起。

3500/33 继电器操作

通常断电 (ND) 或正常通电 (NE) 操作可通过开关选择，用于四组四个通道。

机架空间要求

主模块中有 1 个全高前插槽

1 个用于 I/O 模块的全高后插槽

兼容性

16 通道继电器模块需要 3500 Rack Config 版本 3.3 或更高版本。

16 通道继电器模块需要 2.40 或更高版本的数据采集软件。

16 通道继电器模块需要 3500 数据显示软件 1.40 或更高版本。

如果 16 通道继电器模块是功能安全 (SIL) 系统的一部分，则功能安全证书需要限制电压。对于功能安全 (SIL) 系统，不允许使用更高的电压。
