3500/32 4 通道继电器模块 Bently 141534-01

【产品详情】

需要三重模块冗余 (TMR) 的情况下应使用3500/34 TMR继电

器模块，详细情况请参阅 Bently Nevada 部件号为141534-01

的说明书

4通道继电器模块是一个全高度的模块，它可提供四个

继电器的输出量。任何数量的4通道继电器模块，都可

放置在框架接口模块右边的任一个槽位里。4通道继电

器模块的每个输出都可以独立编程，以执行所需要的

表决逻辑。

每个应用在4通道继电器模块上的继电器，都具有

“报警驱动逻辑”。该报警驱动逻辑可用“与门”和

“或门”逻辑编程，并可利用框架中的任何监测器通

道或任何监测器通道的组合所提供的报警输入(警告或

危险)。该报警驱动逻辑应用框架组态软件编程，可满

足应用中的特殊需要

1) 发光二级管，用来指示继电器通道的情况

2) 用来把继电器触点联到外部设备的终端

3) 控制继电器触点如何工作的开关

4) 4通道继电器及I/O模块

3500/32 4 通道继电器模块 Bently 141534-01

【英文介绍】

Where Triple module redundancy (TMR) is required, 3500/34 TMR relays should be used

Module, see Bently Nevada part number 141534-01 for details

Description of

The 4 channel relay module is a full height module, which can be supplied with four

The output of the relay. Any number of 4-channel relay modules can be used

It is placed in any slot on the right of the frame interface module. 4 channel relay

Each output of the module can be programmed independently to perform what is required

Voting logic.

Each relay applied to a 4-channel relay module has

"Alarm Drive logic". The alarm driver logic can be "and gate" and

The "Or gate" logic is programmed and can be accessed by any monitor in the framework

Channel or any combination of monitor channels provided by the alarm input (warning or

Dangerous). The alarm driver logic application framework configuration software programming can be full

Special needs in foot applications

1) Light emitting diode, used to indicate the condition of relay channel

2) Used to connect the relay contact to the terminal of the external device

3) The switch that controls how the relay contacts work

4) 4-channel relay and I/O module
