BENTLY 3500/22M  瞬态数据接口

【产品详情】

描述

3500/22M瞬态数据接口（TDI）是接口

软件（系统1状态监测和诊断

软件和3500系统配置软件）。TDI

结合3500/20机架接口模块的功能

（RIM）具有通信的数据收集能力

例如TDXnet。

TDI位于与

3500机架。它与M系列监视器（3500/40M，

3500/42M等）以连续收集稳态和

瞬态动态（波形）数据并通过

到主机软件的以太网链路。请参阅

有关详细信息，请参阅本文档末尾的兼容性部分

信息

TDI具有静态数据采集能力。

但是，使用可选的通道启用磁盘将

TDI捕捉动态和高分辨率瞬态数据

也TDI包含通信处理器

3500机架内的功能。

尽管TDI提供某些通用功能

整个机架，它不是关键监控路径的一部分

不影响整体的正常运行

自动机械保护监控系统。每一个

3500机架需要一个TDI或RIM，始终占用插槽

3500/22M动态数据启用

磁盘

此磁盘支持动态数据（即，收集波形）。有两级动态数据。稳态点是收集波形数据的通道

响应软件命令或警报并且因此支持当前值，定时波形.捕获和报警数据俘虏瞬态点,提供所有稳态点的函数波形采集的附加能力,由于参数变化，如机器速度
