6通道温度监测

接受 RTD 和 TC 输入

用户可编程的警报设定点

3500 机架配置软件

每个引线输入大于 10 MΩ

功耗：9瓦

工作温度：-22 至 150°F（-30 至 65°C

Bently Nevada 3500/60 温度监控器提供六个温度监控通道，并接受电阻温度检测器 (RTD) 和热电偶 (TC) 温度输入。这些模块调节这些输入并将它们与用户可编程的警报设置点进行比较。

用户使用 3500 机架配置软件对模块进行编程以执行 RTD 或 TC 温度测量。不同的 I/O 模块可用于 RTD/TC 非隔离或 TC 隔离版本。用户可以配置 RTD/TC 非隔离版本以接受 TC 或 RTD，或 TC 和 RTD 输入的混合。TC 隔离版本提供 250 Vdc 的通道间隔离以防止外部干扰。

在三重模块化冗余 (TMR) 配置中使用时，温度监控器必须以三个为一组并排安装。在此配置中使用时，系统采用两种类型的表决以确保准确操作并避免单点故障。
