BENTLY 3500-05-01-02-00-00-01 3 机架模块使用3500系统机架安装所有3500监视器模块和电源。机架允许您放置3500个模块彼此靠近，使它们能够容易地通信，并安装必要的电源给每个模块分配电源。3500机架有两种尺寸:全尺寸机架。带有14个可用模块插槽的19英寸EIA机架。迷你架。带有七个可用模块插槽的12英寸机架。

3500/05-01-02-00-00-01是Bently Nevada制造的系统机架作为3500/05系列的一部分，用于机械状态监控系统。所有3500监视器模块和机架电源都安装在Bently Nevada 3500/05系统机架中。它使3500模块能够相互作用，并使电源能够根据需要向每个模块分配电力。

3500/05-01-02-00-00-01功能

存放所有3500监视器模块以及机架电源。

有两种尺寸可供选择:全尺寸和微型机架

有三种不同的形式:面板安装，机架安装和舱壁安装都是选项。

试管架位置(7或14)

机架尺寸

有两种尺寸的3500机架可供选择:

全尺寸机架:19英寸EIA机架，有14个模块插槽

迷你机架:12英寸机架，有7个模块插槽

面板安装

这种机架类型通过机架提供的夹具连接到面板上的矩形切口。

从机架背面，您可以接触到接线和I/O模块。

机架固定件

在这种机架类型中，3500机架安装在19英寸EIA导轨上。

从机架背面，您可以接触到接线和I/O模块。

隔板支架

当接触机架背面受到限制时，这种类型的机架会将机架靠在墙上或面板上。从机架正面，您可以接触到接线和I/O模块。这种格式不支持3500/05微型机架。

机架接口模块和电源必须安装在最左侧机架位置。模块的任意组合可用于剩余的14个机架位置(微型机架的7个机架位置)。
