本特利1900/65A通用振动监测器用于对机械振动连续监测和保护。 1900/65A通用振动监测器 应用于：石化炼油厂、发电厂、化工厂、钢铁厂、水处理厂、造纸厂、机械厂、水泵厂、水泥厂和其他行业。1900/65监视器适用于监测和保护机组：冷却塔风机、水泵、鼓风机、电动机、粉碎机、空气压缩机、小型往复式压缩机，小型电动机，小型水轮机，离心机和其他设备机械。

    本特利1900/65A有四个振动输入和四个温度输入，振动通道类型包括：轴振动、轴向位移、转速、速度或加速度。 有六个继电器输出，包括OK、警告和报警状态的逻辑定义，提供四个 4-20 mA记录仪输出。危险地区批准。提供可选的Modbusâ网关，可使监测器将信息输入到分散控制系统（DCS）、可编程控制器（PLC）等客户端。

满量程范围：

振动加速度20至500 m/s2（2 至 50 g）峰值和有效值

振动速度10至50 mm/s（0.5 至2 in/s）峰值和有效值

径向振动100至500μm（3 至20 mils）峰峰值

轴向位移-4.0至+4.0 mm（-150 至+150mils）

精度振动变量： 满量程范围的±1%

电源：输入电压18至36Vdc；工作电流 0.35 A，1.0 A；工作电源8.5 W，18 W

重量：监测器模块：0.77 kg；显示模块：0.40 kg。

安装：35mmDIN导轨安装、壁板安装面板安装或NEMA4X/IP68玻璃纤维防护箱安装

BENTLY 1900/65A-01-02-01-00-00 控制器设备

The Bentley 1900/65A Universal vibration monitor is used for continuous monitoring and protection of mechanical vibrations. 1900/65A General purpose vibration monitors are used in: petrochemical refineries, power plants, chemical plants, steel plants, water treatment plants, paper mills, machinery plants, pump plants, cement plants and other industries. The 1900/65 monitor is suitable for monitoring and protecting units: cooling tower fans, pumps, blowers, electric motors, shredders, air compressors, small reciprocating compressors, small electric motors, small water turbines, centrifuges and other equipment machinery.

The Bentley 1900/65A has four vibration inputs and four temperature inputs, and the vibration channel types include: axial vibration, axial displacement, rotational speed, speed, or acceleration. There are six relay outputs, including logical definitions of OK, warning, and alarm states, providing four 4-20 mA logger outputs. Hazardous area approved. An optional Modbusa gateway is available to enable the monitor to input information to clients such as distributed control systems (DCS), programmable controllers (PLCS), etc.

Full scale range:

Vibration acceleration 20 to 500 m/s2 (2 to 50 g) peak and effective values

Vibration speed 10 to 50 mm/s (0.5 to 2 in/s) peak and effective values

Radial vibration 100 to 500μm (3 to 20 mils) peak-peak value

Axial displacement -4.0 to +4.0 mm (-150 to +150mils)

Precision vibration variable: ±1% of full scale range

Power supply: Input voltage 18 to 36Vdc; Working current 0.35A, 1.0A; Working power supply 8.5W, 18W

Weight: Monitor module: 0.77 kg; Display module: 0.40kg.

Mounting: 35mmDIN rail mounting, panel mounting or NEMA4X/IP68 fiberglass case mounting
