>>>>>型号:1900/65A-00-00-02-00-01 | 通用设备监视器 | 支持远程通信功能
[产品说明]
品牌： Bently Nevada
型号：1900/65A-00-00-02-00-01
产品类型：通用设备监视器
付款方式：电汇，西联
汇款 装运港：中国厦门
交货时间：1-3个工作日
条件：全新和 100% 原始
保修：12 个月
特征：
●24位ADC转换
●四个振动/位置速度输入
●四个温度输入
●可配置的比例因子和满量程范围
●内部OK检查状态
●独立的警报和危险设定点
●200 个条目事件列表
●6个继电器输出
●继电器操作是可编程的
●每个传感器通道的缓冲输出
●4个可配置的4-20 mA记录器输出
本特利内华达 1900/65A 通用设备监控器旨在持续监控和保护用于各种应用和行业的设备。该显示器的低成本使其成为通用机器和过程的理想解决方案，可以从持续监控和保护中受益。
1900/65A 提供 4 个传感器输入和 4 个温度输入。软件可以配置每个传感器输入，以支持 2 线和 3 线加速度计、速度传感器或接近传感器。每个温度输入都支持 E、J、K 和 T 型热电偶以及 2 线或 3 线 RTD。
1900/65A 提供 6 个继电器输出、4 个 4-20 mA 记录器输出和一个专用缓冲输出。用户可以使用 1900 Configuration 软件将继电器触点配置为根据任何通道或通道组合的 OK、Alert 和 Danger 状态打开或关闭，并在任何记录仪输出上提供来自任何通道的任何变量的数据。专用缓冲器输出可以为每个传感器输入提供信号。
产品背景：
该控制主板模块由Bently Nevada(现称为Bentley Systems的一部分)制造，最初专注于旋转机械保护和状态监测。
它可能是Bently Nevada曾经生产过的一个特定型号的控制主板，用于旋转机械的状态监测、保护和控制。
功能特点：
振动监测和分析：该模块能够实时监测和分析设备振动信号，通过内置算法处理振动数据，以提供设备状态信息。
数据采集和存储：具有高速数据采集能力，可高精度、高频率地采集和存储设备振动、温度、压力等数据。
实时报警和诊断：根据预设的报警阈值和诊断算法，监测设备故障、异常和趋势，及时发出警报。
远程通信和控制：支持远程通信功能，如以太网或串口接口，便于与其他设备或监测系统进行数据交换和远程控制。
可靠性和稳定性：采用高质量的电路设计和可靠的组件，能在恶劣的工业环境下正常运行，并具备抗干扰和抗振动能力。
技术参数：
输入：提供四个传感器输入和四个温度输入，可配置以支持2线和3线加速度计、速度传感器或接近传感器。每个温度输入支持E、J、K和T型热电偶以及2线或3线RTD。
输出：提供六个继电器输出、四个4-20 mA记录器输出和一个专用缓冲输出。用户可根据OK、Alert和危险状态配置输出。
通信：支持通过以太网和软件可配置的Modbus通信RS232/485串口。Modbus网关选项允许监视器将静态变量、状态、事件列表、时间和日期信息发送到Modbus客户端。
[其他型号推荐]
>>>>> Model :1900/65A-00-00-02-00-01 | General equipment monitor | supports the remote communication function
Brand: Bently Nevada
Model: 1900/65A-00-00-02-00-01
Product type: Universal device monitor
Payment method: Wire transfer, Western Union
Port of shipment for remittance: Xiamen, China
Delivery time: 1-3 working days
Condition: New and 100% original
Warranty: 12 months
trait：
● 24-bit ADC conversion
● Four vibration/position speed inputs
● Four temperature inputs
● Configurable scale factor and full scale range
● Internal OK check status
● Independent alarm and danger set points
●200 item event list
●6 relay outputs
● Relay operation is programmable
● Buffer output for each sensor channel
● Four configurable 4-20 mA logger outputs
Bentley Nevada 1900/65A Universal Device monitors are designed to continuously monitor and protect equipment used in a variety of applications and industries. The low cost of this display makes it an ideal solution for general-purpose machines and processes that can benefit from continuous monitoring and protection.
The 1900/65A offers 4 sensor inputs and 4 temperature inputs. The software can configure each sensor input to support 2-wire and 3-wire accelerometers, speed sensors, or proximity sensors. Each temperature input supports E, J, K, and T thermocouples as well as 2-wire or 3-wire RTDS.
The 1900/65A offers six relay outputs, four 4-20 mA recorder outputs, and a dedicated buffer output. Users can use the 1900 Configuration software to configure relay contacts to open or close according to the OK, Alert and Danger states of any channel or combination of channels, and to provide data on any variable from any channel on any logger output. A dedicated buffer output can provide a signal for each sensor input.
Product background:
The control motherboard module, manufactured by Bently Nevada (now part of Bentley Systems), initially focused on rotating machinery protection and condition monitoring.
It may be a specific type of control board once produced by Bently Nevada for condition monitoring, protection and control of rotating machinery.
Functional features:
Vibration Monitoring and analysis: The module is capable of real-time monitoring and analysis of equipment vibration signals, processing vibration data through built-in algorithms to provide equipment status information.
Data acquisition and storage: with high-speed data acquisition capabilities, it can collect and store device vibration, temperature, pressure and other data with high precision and high frequency.
Real-time alarm and diagnosis: Monitor equipment failures, anomalies and trends according to preset alarm thresholds and diagnosis algorithms, and issue alarms in time.
Remote communication and control: Support for remote communication functions, such as Ethernet or serial ports, to facilitate data exchange and remote control with other devices or monitoring systems.
Reliability and stability: With high-quality circuit design and reliable components, it can operate normally in harsh industrial environments, and has anti-interference and anti-vibration capabilities.
Technical parameters:
Inputs: Four sensor inputs and four temperature inputs are available and can be configured to support 2 - and 3-wire accelerometers, speed sensors, or proximity sensors. Each temperature input supports E, J, K, and T thermocouples and 2 - or 3-wire RTDS.
Outputs: Six relay outputs, four 4-20 mA recorder outputs, and one dedicated buffer output are available. Users can configure the output according to OK, Alert, and danger states.
Communication: Support RS232/485 serial port communication over Ethernet and software-configurable Modbus. The Modbus Gateway option allows the monitor to send static variables, status, event list, time and date information to the Modbus client.
