☆型号:DPO5054B 混合信号示波器 两条通道上高达 10 GS/s 的实时采样率
【产品详情】
主要特性
2 GHz、1 GHz、500 MHz、350 MHz 四种带宽型号
一条或两条通道上高达 10 GS/s 的实时采样率,所有通道上高达 5 GS/s 的采样率
MultiView zoom™ 高达 250 M点记录长度
FastAcq® 采集技术,>250
DPO5054B是Tektronix(泰克)公司推出的一款混合信号示波器,属于MSO/DPO5000B系列。这款示波器提供了高达2 GHz的带宽和10 GS/s的采样率,使得它能够捕捉和分析高速信号。此外,DPO5054B还具备优异的信号保真度,为工作台和实验室的应用提供了可靠的信号分析解决方案。
在功能方面,DPO5054B提供了多种触发组合,包括建立/保持、串行包内容和并行数据,从而能够快速捕获信号异常。它还支持可选的视觉触发,允许图形触发定义,进一步增强了触发功能。此外,DPO5054B内置了53种自动测量、测量统计、直方图、波形数学、用户可定义的滤波器以及自定义MATLAB和.NET数学插件,这些工具可以帮助用户对设备进行深入的分析。
在显示方面,DPO5054B提供了四条模拟通道和16条数字通道,能够同时分析模拟信号和数字信号,适用于复杂设计的系统级故障排除。它还支持FastAcq®采集技术,能够以大于250,000波形/秒的速度快速捕获毛刺和偶发事件,从而帮助用户更快地显示难检的异常。
此外,DPO5054B还提供了HiRes采集功能,通过增加垂直分辨率到11位以上,同时降低信号噪声,从而提高了信号捕获的精度。这一功能对于在捕获高幅度信号的同时看到更小的信号细节非常有用。
总的来说,DPO5054B是一款功能丰富、性能卓越的混合信号示波器,适用于各种高速信号分析和故障排除应用。无论是工作台还是实验室环境,它都能提供可靠的信号分析解决方案。
【英文介绍】
Main characteristics
2 GHz, 1 GHz, 500 MHz, 350 MHz four bandwidth models
Real-time sampling rates of up to 10 GS/s on one or two channels and up to 5 GS/s on all channels
MultiView zoom™ Up to 250 M point recording length
FastAcq® Acquisition technology, >250
The DPO5054B is a mixed-signal oscilloscope from Tektronix that belongs to the MSO/DPO5000B series. The oscilloscope offers bandwidth up to 2 GHz and a sampling rate of 10 GS/s, allowing it to capture and analyze high-speed signals. In addition, the DPO5054B offers excellent signal fidelity, providing a reliable signal analysis solution for workbench and laboratory applications.
In terms of functionality, the DPO5054B offers a variety of trigger combinations, including build/hold, string packet content, and parallel data, enabling rapid capture of signal anomalies. It also supports optional visual triggers, allowing graphical triggers to be defined, further enhancing the trigger functionality. In addition, the DPO5054B comes with 53 automatic measurements, measurement statistics, histograms, waveform mathematics, user-defined filters, and custom MATLAB and MATLAB. NET Math plugins, these tools can help users conduct in-depth analysis of the device.
In terms of display, the DPO5054B offers four analog channels and 16 digital channels, capable of analyzing both analog and digital signals at the same time, and is suitable for system-level troubleshooting of complex designs. It also supports FastAcq® acquisition technology, which quickly captures burrs and contingencies at speeds greater than 250,000 waveforms per second, helping users display hard-to-detect anomalies faster.
In addition, the DPO5054B offers HiRes acquisition capabilities that improve the accuracy of signal acquisition by increasing the vertical resolution to more than 11 bits while reducing signal noise. This feature is useful for seeing smaller signal details while capturing a high-amplitude signal.
Overall, the DPO5054B is a feature-rich, high-performance mixed-signal oscilloscope for a variety of high-speed signal analysis and troubleshooting applications. Whether it is a workbench or a laboratory environment, it provides reliable signal analysis solutions.
