3500/05-01-01-00-00-00 框架模块 系统机架

☆型号：3500/05-01-01-00-00-00 框架模块 系统机架

【产品详情】

特征：

可容纳所有 3500 显示器模块和机架电源

制造有 （2） 种尺寸：全尺寸机架和迷你机架

以 （3） 种形式制造：面板安装、机架安装和隔板安装

7 或 14 个机架位置

GE / Bently Nevada 3500/05 系统机架设计可容纳所有 3500 显示器模块和机架电源 用品。它允许各种 3500 模块相互通信 以及根据需要为每个模块分配电源的电源。

3500 机架有两种尺寸： 1. 全尺寸机架：

19 英寸 EIA 机架，带 14 个可用模块插槽

2.Mini-Rack：12 英寸机架，带 7 个可用模块插槽

框架接口模块(RIM)是3500框架的基本接口。它支持本特利用于框架组态并调出机组中信息的专有协议。框架接口模块必须放在框架中的第一个槽位(紧靠电源的位置)。 RIM 可以与兼容的本特利通讯处理器，如TDXnet、TDIX 和DDIX 等连接。虽然RIM 为整个框架提供某些通用功能，但它并不是重要监测路径中的一部分，对整个监测系统的正确和正常运行没有影响。每个框架需要一个框架接口模块。

其前面板上有RS-232 串行接口，可以与主机连接进行数据采集和框架组态，波特率最大38.4K，电缆长度要求最长30m。后面的I/O（输入/输出）模块上有 RS-232/RS-422 串行接口，同样可以与主机连接进行数据采集和框架组态，最大波特率38.4K，电缆长度：RS232为最长30m，RS422为最长1200m。RS422接口还能使使多台3500框架以链连接同3500 主机软件进行通讯。

☆型号：3500/05-01-01-00-00-00 框架模块 系统机架

【英文介绍】

Features:

Can accommodate all 3500 display modules and rack power supply

Manufactured in (2) sizes: full size rack and mini rack

Manufactured in (3) forms: panel mount, rack mount and partition mount

7 or 14 rack positions

The GE/Bently Nevada 3500/05 system rack is designed to accommodate all 3500 display modules and rack power supplies. It allows various 3500 modules to communicate with each other as well as a power supply that allocates power to each module as needed.

3500 rack available in two sizes: 1. Full size rack:

19-inch EIA rack with 14 available module slots

2.Mini-Rack: A 12-inch rack with seven available module slots

The Framework Interface Module (RIM) is the basic interface of the 3500 framework. It supports Bent's proprietary protocols for framing and retrieving information from the unit. The frame interface module must be placed in the first slot in the frame (next to the power supply). RIM can connect with compatible Bentley communication processors such as TDXnet, TDIX, and DDIX. Although RIM provides some common features for the entire framework, it is not part of the critical monitoring path and has no impact on the correct and normal operation of the overall monitoring system. Each framework requires a framework interface module.

There is a RS-232 serial interface on the front panel, which can be connected with the host for data acquisition and frame configuration, the baud rate is up to 38.4K, and the cable length is required to be up to 30m. The rear I/O (input/output) module has a RS-232/RS-422 serial interface, which can also be connected with the host for data acquisition and frame configuration, the maximum baud rate of 38.4K, the cable length: RS232 is the longest 30m, RS422 is the longest 1200m. The RS422 interface also enables multiple 3500 frames to communicate with the 3500 host software in a chain connection.
