3500/93 135799-01 显示接口模块 位移监测器模块

☆型号：3500/93 135799-01 显示接口模块 位移监测器模块

【产品详情】

美国Bently本特利4通道位移监测器模块3500/40M-01-00 它可以接受Bently本特利位移传感器的输入，对这些信号进行处理后生成各种不同的振动和位移测量，并将处理后的信号与用户编程的报警设定值进行比较。可以使用3500框架组态软件对3500/40M的每个通道进行组态编程，使其具有以下功能：

*径向振动

*轴向位移

*差胀

*轴偏心

* REBAM

注：该监测器通道成对组态，一次zui多可执行上述功能中的2个，通道1和通道2执行一个功能，通道3和通道4执行另一个功能。

3500/40M监测器主要功能为：

1.通过连续不断地将机器振动当前值与组态中的组态值进行比较，并驱动报警系统，从而达到保护机器的目的；

2. 为操作人员和维护人员提供关键设备的振动信息；

通过组态，每一通道通常将输入信号处理成“静态值”。每一静态值都有组态好的警告报警值，每两个静态值都有组态一个危险报警值。

技术规格：

输入信号：接收1到4个位移传感器信号；

输入阻抗：标准I/O(输入/输出模块):10kΩ；TMR(三重冗余模块)I/O：三个总线式TMR I/O并联到一个传感器的有效阻抗为50kΩ

功耗：额定值 7W

灵敏度：

径向振动: 3.94mV/μm (100mV/mil) 或7.87mV/μm (200mV/mil);

轴位移: 3.94mV/μm (100mV/mil) 或 7.87mV/μm (200mV/mil);

偏心: 3.94mV/μm (100mV/mil) 或 7.87mV/μm (200mV/mil);

差胀: 0.394mV/μm (10mV/mil) 或 0.787mV/μm (20mV/mil);

REBAM: 40mV/μm (1000mV/mil) 或 80mV/μm (2000mV/mil);

输出:

前面板LED（发光二极管）

OK LED: 指示3500/40M运行正常;

TX/RX LED: 指示3500/40M正与3500框架内的其它模块进行通讯；

Byposs旁路 LED: 指示3500/40M处于旁路模式。

传感器缓冲输出: 在监测器的前面板，对应每一通道均有同轴接头，每一接头均有短路保护。

输出阻抗: 550Ω。

传感器电源: -24VDC

环境限制：

 运行温度：当使用内部/外部端子I/O模块时：-30℃到65℃(-22至150)

 储存温度：当使用带内部安全栅的I/O模块（内部端子）时：-40℃到85℃(-40至185)

 湿度：95%，不冷凝

电磁兼容性：

EMC指标 *性认证：136669

EN50081-2：

 放射辐射EN55011，A类；

 传导辐射EN55011，A类；

EN50082-2：

 静电放电EN61000-4-2,标准B;

 放射灵敏度ENV50140，标准A;

 传导灵敏度ENV50141，标准A;

 瞬间导电EN61000-4-4,标准B;

 电涌容量EN61000-4-5,标准B;

 磁场EN61000-4-8,CriteriaA

 电源偏差EN61000-4-11 标准B;

 无线电干扰ENV50204，标准B;

危险地区批准 CSA/NRTL/C:当使用内部/外部端子I/O模块时，1类 2区 A组至D组

批准号：BN26744C-18 当使用当使用内部/外部端子I/O模块时，请参照产品说明书141495-1查阅批准信息；

物理特性：

监测器模块主板外形尺寸：（高241.3mmX宽24.4mmX深241.8mm）重量：0.91kg;

I/O模块(无安全栅）：（高241.3mmX宽24.4mmX深99.1mm）重量：0.20kg;

I/O模块(带安全栅）：（高241.3mmX宽24.4mmX深163.1mm）重量:0.46kg;

订货信息：

位移监测器

3500/40-AXX-BXX

选项描述

A: I/O 模块类型

01 带内部端子的位移I/O模块;

02 带外部端子的位移I/O模块;

03 带内部安全栅和带内部端子的位移I/O模块；

04 带外部端子的TMR位移I/O模块；

B: 批准机构选项

00 无

01 CSA/NRTL/C

外部端子块：

125808-01 位移监测器外部端子块(欧式接头)；

128015-01 位移监测器外部端子块(端子带接头)。

132242-01 位移/速度加速度总线型三重冗余外部端子块(欧式接头)。

132234-01 位移/速度加速度总线型三重冗余外部端子块(端子带接头)。

电缆

3500传感器（XDCR）信号到外部端子（ET）块电缆

选项说明：129525-AXXXX-BXX

A:电缆长度

 0005 5英尺（1.5米）

 0007 7英尺（2.1米）

 0010 5英尺（3米）

 0025 25英尺（7.5米）

 0050 50英尺（15米）

☆型号：3500/93 135799-01 显示接口模块 位移监测器模块

【英文介绍】

USA Bently Bentley 4-channel displacement monitor module 3500/40M-01-00 It can accept input from Bently Bentley displacement sensors, process these signals to generate a variety of different vibration and displacement measurements, and compare the processed signals with user-programmed alarm setpoints. Each channel of 3500/40M can be configured using the 3500 Framework configuration software so that it has the following features:

* Radial vibration

* Axial displacement

Differential expansion

* shaft eccentricity

* REBAM

Note: The monitor channels are configured in pairs so that at most 2 of the above functions can be performed at a time, with channels 1 and 2 performing one function and channels 3 and 4 performing another function.

The main functions of 3500/40M monitor are:

1. By continuously comparing the current value of the machine vibration with the configuration value in the configuration, and driving the alarm system, so as to achieve the purpose of protecting the machine;

2. Provide vibration information of key equipment for operators and maintenance personnel;

Through configuration, each channel usually processes the input signal into a "static value". Each static value has a configured warning alarm value, and each two static values has a configured danger alarm value.

Technical specifications:

Input signal: Receive 1 to 4 displacement sensor signals;

Input impedance: Standard I/O(input/output module):10kΩ; TMR(Triple Redundant Module)I/O: Three bus TMR I/ OS in parallel to one sensor have an effective impedance of 50 kω

Power consumption: Rated 7W

Sensitivity:

Radial vibration: 3.94mV/μm (100mV/mil) or 7.87mV/μm (200mV/mil);

Axial displacement: 3.94mV/μm (100mV/mil) or 7.87mV/μm (200mV/mil);

Eccentricity: 3.94mV/μm (100mV/mil) or 7.87mV/μm (200mV/mil);

Differential expansion: 0.394mV/μm (10mV/mil) or 0.787mV/μm (20mV/mil);

REBAM: 40mV/μm (1000mV/mil) or 80mV/μm (2000mV/mil);

Output:

Front panel LED (Light Emitting Diode)

OK LED: indicates that 3500/40M is operating normally;

TX/RX LED: indicates that 3500/40M is communicating with other modules in the 3500 frame;

Byposs Bypass LED: indicates that 3500/40M is in bypass mode.

Sensor buffer output: In the front panel of the monitor, there are coaxial connectors corresponding to each channel, and each connector is protected by short circuit.

Output impedance: 550Ω.

Sensor power supply: -24VDC

Environmental restrictions:

Operating temperature: When using internal/external terminal I/O modules: -30℃ to 65℃(-22 to 150)

Storage temperature: When using I/O modules with internal safety bars (internal terminals) : -40 ° C to 85 ° C (-40 to 185)

Humidity: 95%, non-condensing

Electromagnetic compatibility:

EMC index * Certification: 136669

EN50081-2:

Radioactive radiation EN55011, Class A;

Conducted radiation EN55011, Class A;

EN50082-2:

Electrostatic discharge EN61000-4-2, Standard B;

Radiation sensitivity ENV50140, Standard A;

Conduction sensitivity ENV50141, Standard A;

Instant conduction EN61000-4-4, Standard B;

Surge capacity EN61000-4-5, Standard B;

Magnetic field EN61000-4-8,CriteriaA

Power supply deviation EN61000-4-11 Standard B;

Radio interference ENV50204, Standard B;

Hazardous Area Approved CSA/NRTL/C: Class 1 Zone 2 Group A to Group D when using internal/external terminal I/O modules

Approval Number: BN26744C-18 When using When using the internal/external terminal I/O module, please refer to the product manual 141495-1 for approval information;

Physical characteristics:

Monitor module motherboard dimensions: (H 241.3mmX W 24.4mmX D 241.8mm) Weight: 0.91kg;

I/O module (without safety gate) : (H 241.3mmX W 24.4mmX D 99.1mm) Weight: 0.20kg;

I/O module (with safety grid) : (H 241.3mmX W 24.4mmX D 163.1mm) Weight :0.46kg;

Ordering information:

Displacement monitor

3500/40-AXX-BXX

Option description

A: Type of the I/O module

01 Displacement I/O module with internal terminals;

02 Displacement I/O module with external terminals;

03 Displacement I/O modules with internal safety bars and internal terminals;

04 TMR displacement I/O module with external terminals;

B: Approval authority option

00 None

01 CSA/NRTL/C

External terminal block:

125808-01 Displacement monitor external terminal block (European connector);

128015-01 Displacement monitor external terminal block (terminal with connector).

132242-01 Displacement/Velocity acceleration bus triple redundant external terminal block (European joint).

132234-01 Displacement/Velocity acceleration bus triple redundant external terminal block (terminal with connector).

cable

3500 Sensor (XDCR) signal to external terminal (ET) block cable

Option description: 129525-AXXXX-BXX

A: Cable length

0005 5 feet (1.5 m)

0007 feet (2.1 m)

0010 5 feet (3 m)

0025 25 feet (7.5 m)

0050 50 feet (15 m)
