3500/22M 138607-01 接口模块 高分辨率的瞬态数据

☆型号：3500/22M 138607-01 接口模块 高分辨率的瞬态数据

【产品详情】

本特利内华达机械状态监测

描述

接口为3500/22M TDI (Transient Data Interface)接口

与3500监控系统之间兼容

软件(系统1)状态监测和诊断

软件和3500系统配置软件)。TDI的

具备3500/20机架接口模块的功能

(RIM)具有数据采集能力的一种通信方式

处理器，如TDXnet。

TDI位于a电源旁边的槽位

3500架。它与M系列监视器(3500/40M，

3500/42M等)连续采集稳态和

暂态动态(波形)数据并通过传递此数据

到主机软件的以太网链路。参考

有关更多信息，请参阅本文档末尾的兼容性部分

信息。

静态数据捕获功能是TDI的标准配置。

但是，使用可选的通道启用磁盘将允许

TDI捕获动态和高分辨率的瞬态数据

也。TDI集成了通信处理器

功能在3500机架内。

虽然TDI提供了一些通用的功能

整个机架，它不是关键监控路径的一部分

不影响正常、整体的正常运行

自动机械保护监控系统。每一个

3500机架需要1个TDI或RIM，总是占用Slot

1(电源旁边)。

☆型号：3500/22M 138607-01 接口模块 高分辨率的瞬态数据

【英文介绍】

Bently Nevada Machinery Condition Monitoring

Description

The 3500/22M Transient Data Interface (TDI) is the interface

between the 3500 monitoring system and compatible

software (System 1 Condition Monitoring and Diagnostic

software and 3500 System Configuration software).  The TDI

combines the function of a 3500/20 Rack Interface Module

(RIM) with the data collection capability of a communication

processor such as TDXnet.

The TDI resides in the slot adjacent to the power supplies of a

3500 rack.  It interfaces with M series monitors (3500/40M,

3500/42M, etc.) to continuously collect steady state and

transient dynamic (waveform) data and pass this data through

an Ethernet link to the host software.  Refer to the

Compatibility section at the end of this document for more

information.

Static data capture capability is standard with the TDI.

However, using an optional Channel Enabling Disk will allow

the TDI to capture dynamic and high-resolution transient data

as well.  The TDI incorporates the communication processor

function within the 3500 rack.

Although the TDI provides certain functions common to the

entire rack, it is not part of the critical monitoring path and has

no effect on the proper, normal operation of the overall

monitor system for automatic machinery protection.  Every

3500 rack requires one TDI or RIM, which always occupies Slot

1 (next to the power supplies).
