3500/40 135489-04 前置器I/O模块 来自接近传感器的输入

☆型号：3500/40 135489-04 前置器I/O模块 来自接近传感器的输入

【产品详情】

135489-04是Bently Nevada开发的带外部终端的前置器I/O模块。该组件是3500/40m的一部分，它是一个四通道监视器，接受来自接近传感器的输入，调节信号以提供各种振动和位置测量，并将调节后的信号与用户可编程报警进行比较。

功能描述

Proximitor监视器是一个四通道监视器，接受来自Bently Nevada接近传感器的输入，调节信号以提供各种振动和位置测量，并将调节后的信号与用户可编程报警进行比较。3500框架配置软件允许用户对3500/40M的每个通道进行编程，以执行各种功能。

135489-04功能

前置监视器的主要职责是提供以下功能:

通过持续比较监控参数和配置的报警设定值来驱动报警，从而保护机器

操作和维护人员的关键机器信息

根据配置，每个通道通常会调理其输入信号，以产生一组称为静态值的参数。您可以为每个活动静态值设置报警设定点，为任意两个活动静态值设置危险设定点。

☆型号：3500/40 135489-04 前置器I/O模块 来自接近传感器的输入

【英文介绍】

The 135489-04 is a preprocessor I/O module with external terminals developed by Bently Nevada. The component is part of the 3500/40m, which is a four-channel monitor that accepts input from proximity sensors, adjusts the signal to provide various vibration and position measurements, and compares the adjusted signal to a user-programmable alarm.

Function description

The Proximitor monitor is a four-channel monitor that accepts input from the Bently Nevada proximity sensor, adjusts the signal to provide various vibration and position measurements, and compares the adjusted signal to a user-programmable alarm. The 3500 framework configuration software allows users to program each channel of the 3500/40M to perform various functions.

135489-04 Functions

The primary responsibility of the front monitor is to provide the following functions:

Protect the machine by continuously comparing monitoring parameters and configured alarm Settings to drive alarms

Critical machine information for operation and maintenance personnel

Depending on the configuration, each channel typically adjusts its input signal to produce a set of parameters called static values. You can set an alarm set point for each active static and a danger set point for any two active static values.

☆型号：3500/40 135489-04 前置器I/O模块 来自接近传感器的输入
